Our Facade Cladding System with Ceramic Roof Tiles combines aesthetic appeal with exceptional durability, offering architects and builders a premium solution for exterior protection and design flexibility. This innovative system is engineered to withstand harsh weather conditions while maintaining its elegant appearance for decades.
| Parameter | Value |
|---|---|
| Material Composition | High-grade ceramic with protective glaze |
| Tile Dimensions | 300mm x 600mm (standard), Custom sizes available |
| Weight | 18-22 kg/m² |
| Color Options | 12 standard colors, Custom colors available |
| Temperature Resistance | -40°C to +120°C |
| Warranty | 30-year limited warranty |
| Installation System | Interlocking mechanical fixing system |
Our ceramic facade system is perfect for:
Compared to conventional facade materials, our solution offers:
Facade System terracotta tiles
FACING MATERIAL:
horizontally oriented solid and hollow terracotta tiles
FIXING:
concealed with clamps or hold-down bars（AOZ-T-35）
MAX FACING SIZES:
600x1000mm(horizontally and vertically).
FACING MATERIAL:
vertically oriented solid and hollow terracotta tiles
FIXING:
concealed with stainless steel clamps(AOZ-T-25)
MAX FACING SIZES:
600x1000mm
FACING MATERIAL:
horizontally oriented solid and hollow terracotta tiles
FIXING:
concealed with clamps fixed to horizontal bars(AOZ-T-45)
MAX FACING SIZES:600x1000mm
Aluminum / stainless steel sub-construction for invisible clip fixing of terracotta panels.
The construction consists of brackets and vertical holding tracks. The holding tracks
are either used for mounting different holding clips or different system rails including their specific holders. The brackets are used to form sliding points and fixed points. The sliding points only bear horizontal loads, the fixed points bear horizontal and vertical loads with standard protrusions of up to 480 mm.
Facade System A0Z-v-300FACING MATERIAL:Large-sized porcelain stoneware tiles 3 to 6 mm thick.FIXING:Concealed with latches (slide holders and cassette...
See Details
Facade System A0Z-v-300FACING MATERIAL:Large-sized porcelain stoneware tiles 3 to 6 mm thickFIXING:Mixed: visible with mechanically mounted three-part...
See Details
Facade System A0Z-v-350FACING MATERIAL: Ceramic roof tilesFIXING:Concealed with tiles fixed to horizontal bars with self. tapping screw and wind clamp...
See Details
The honeycomb panel pendant mainly consists of the following accessories:Pendant body: This is the core part of the pendant, which is usually made of ...
See Details
Facade System A0Z-v-300FACING MATERIAL:Tempered glass and stimulate 4 to 8 mm thickFIXING:Concealed with latches (slide holders and cassette hangers),...
See Details
● Material : Stainless Steel 1.4301 [A2) & 1.4401 [A4]● The table above is prepared according to LGA test results● Loads stated are characteristic...
See Details
Stainless Steel Anchor Channel Pair is an important construction and engineering material popular for its corrosion resistance and high strength prope...
See Details
The honeycomb panel pendant mainly consists of the following accessories:Pendant body: This is the core part of the pendant, which is usually made of ...
See DetailsJiangsu Aozheng Metal Products Co., Ltd.is a professional industry and trade integrated enterprise, with a modern production plant covering an area of 32,000 square meters. We specialize in the R&D, production and supply of a full range of high-quality construction hardware products. Our core product portfolio includes exterior wall cladding fixing system brackets, C channels, seismic support brackets, anchor bolts, cast-in channels, concrete embedded parts and photovoltaic bracket clamps, which cater to various customized construction and engineering installation requirements. Our products are manufactured from premium raw materials including stainless steel, aluminum alloy, carbon steel and low alloy steel. Equipped with advanced industrial production technologies, we adopt automated cutting, extrusion, stamping, welding, CNC machining and laser processing craftsmanship. Strict standardized production and precise processing procedures are implemented throughout production to ensure stable, reliable and high-standard product quality. Integrating raw material forming and mechanical processing, our factory operates as a large-scale, diversified and professional manufacturing base for construction hardware. Upholding strict quality standards and high-end global market positioning, we achieve an annual production capacity of 8,000 tons of diverse building materials. Our products are widely exported to dozens of countries and regions across the globe, covering the United States, Germany, Italy, Belgium, the United Kingdom, Japan, Australia, Canada, Russia, Central Asia and the Middle East. We have established long-term, stable and strategic cooperative relationships with large construction enterprises and renowned engineering teams worldwide. Supported by superior product quality and professional all-round services, we have become a core and trusted building material supplier for our global partners in China.
