U Strut Channel Manufacturers

U strut channel is typically made from materials such as steel or aluminum, providing strength and durability. It is commonly available in various sizes and gauges to accommodate different load-carrying requirements.
U strut channel is designed with evenly spaced holes or slots along its length. These holes or slots allow for easy attachment of bolts, nuts, or other fasteners, making it a versatile mounting system for various applications. is available in different finishes, including plain, pre-galvanized, or stainless steel, to suit different environmental conditions or aesthetic preferences.
About Us
Jiangsu Aozheng Metal Products Co., Ltd.

Jiangsu Aozheng Metal Products Co., Ltd. is a professional industry and trade integrated enterprise, with a modern production plant covering an area of 32,000 square meters. We specialize in the R&D, production and supply of a full range of high-quality construction hardware products. Our core product portfolio includes exterior wall cladding fixing system brackets, C channels, seismic support brackets, anchor bolts, cast-in channels, concrete embedded parts and photovoltaic bracket clamps, which cater to various customized construction and engineering installation requirements. Our products are manufactured from premium raw materials including stainless steel, aluminum alloy, carbon steel and low alloy steel. Equipped with advanced industrial production technologies, we adopt automated cutting, extrusion, stamping, welding, CNC machining and laser processing craftsmanship. Strict standardized production and precise processing procedures are implemented throughout production to ensure stable, reliable and high-standard product quality. Integrating raw material forming and mechanical processing, our factory operates as a large-scale, diversified and professional manufacturing base for construction hardware. Upholding strict quality standards and high-end global market positioning, we achieve an annual production capacity of 8,000 tons of diverse building materials. Our products are widely exported to dozens of countries and regions across the globe, covering the United States, Germany, Italy, Belgium, the United Kingdom, Japan, Australia, Canada, Russia, Central Asia and the Middle East. We have established long-term, stable and strategic cooperative relationships with large construction enterprises and renowned engineering teams worldwide. Supported by superior product quality and professional all-round services, we have become a core and trusted building material supplier for our global partners in China.

Certificate Of Honor
  • High-Tech Enterprises
  • Made in China Network Certification
  • Business License
  • Opening Permit
  • Jiangsu Private Science & Technology Enterprise
  • A heavy-duty combined stone pendant
  • An integrated stone back bolt
  • An integrated expansion ring and a back bolt with an integrated expansion ring
News
Message Feedback
U Strut Channel Industry knowledge

What are the standard sizes of U Strut Channel?

The standard sizes of U Strut Channel usually vary due to different manufacturers and regional standards, but the common sizes mainly involve its width, height and thickness. Here are some common standard sizes of U Strut Channel:

Common U Strut Channel Sizes
Width
41 mm (1-5/8 inches): This is one of the most common standard widths and is used in most applications.
21 mm (13/16 inches): Used for lighter support structures.
82 mm (3-1/4 inches): Used for heavier load support structures.

Height
21 mm (13/16 inches)
41 mm (1-5/8 inches)
62 mm (2-7/16 inches)
75 mm (3 inches)

Thickness
1.5 mm (0.059 inches)
2.0 mm (0.079 inches)
2.5 mm (0.098 inches)
3.0 mm (0.118 inches): Used for higher load requirements.

Other Parameters
Length: Standard lengths are usually 3 meters (about 10 feet) and 6 meters (about 20 feet), but they can also be customized according to specific needs.
Hole Configuration: U Strut Channel usually has pre-drilled holes for quick installation and connection. Hole spacing and diameter may vary according to specific application needs.
Special Sizes and Customization
In addition to standard sizes, U Strut Channel can also be customized according to the needs of specific projects. This includes adjusting the length, hole spacing, special coatings, etc. to meet specific design and functional requirements.

Choosing the right size usually depends on the application scenario, load-bearing capacity, installation requirements, and environmental conditions. In engineering and construction projects, choosing the right U Strut Channel is an important factor in ensuring structural safety and effective support. If there are specific project requirements, it is recommended to communicate with the supplier to determine the most suitable product specifications.

Can U Strut Channel be customized?

U Strut Channel can be customized according to specific needs. This customization can be done in many aspects to ensure that it meets the requirements and application scenarios of specific projects. Here are some common customization options:

1. Length
Customized length: Although the standard length is usually 3 meters (about 10 feet) or 6 meters (about 20 feet), it can be custom cut according to the specific needs of the project to accommodate special installation requirements or space constraints.
2. Hole configuration
Hole spacing and size: The spacing, diameter and shape of the holes can be customized according to specific installation needs. This allows for more flexible installation and fixing of different types of equipment or components.
3. Material selection
Material types: In addition to standard hot-dip galvanized steel and stainless steel, special alloys or coating materials can be selected to improve corrosion resistance or meet specific strength requirements.
Coating and surface treatment: Different surface treatments can be selected, such as powder coating, electrogalvanizing, etc., to adapt to different environmental conditions (such as marine environments or chemical environments).
4. Shapes and Specifications
Special Shapes: In certain cases, U Strut Channel with special cross-sections can be designed to meet special load or installation requirements.
Reinforced Structures: For applications that require additional strength, thicker materials or additional reinforcement structures may be customized.
5. Accessories and Attachments
Customized Accessories: Special brackets, clamps and connectors can be designed and produced to ensure compatibility and integration with other systems and components.
6. Application Scenarios
Specific Industry Applications: Customized product solutions are provided according to the special requirements of different industries (such as power, communications, petrochemicals, etc.) to ensure product applicability and performance.
7. Color and Marking
Color and Marking: According to customer requirements, specific colors are painted or marked for easy identification and classification.
