Color Steel Tile Angle Fixture, Aluminum Alloy Photovoltaic Bracket

The Color Steel Tile Angle Fixture is a precision-engineered mounting component designed for the integration of photovoltaic modules onto industrial roofing surfaces. Manufactured from 6005-T5 aluminum alloy, this aluminum clamp provides a non-penetrative fastening solution, ensuring the structural integrity of the roof remains intact while securing the solar racking system. The fixture is specifically compatible with standing seam and angled rib profiles common in commercial and industrial architecture.

Get A Quote

Photovoltaic mounting solution

Technical Overview of Color Steel Tile Angle Fixture

Non-penetrative clamping | Corrosion-resistant alloy | 25-year service design

Structural Features and Material Properties

Utilizing high-strength extruded aluminum alloy, the fixture exhibits significant resistance to atmospheric corrosion. The surface undergoes a 10-15 micron anodic oxidation treatment, which establishes a protective barrier against oxidative degradation in saline or humid environments. This photovoltaic bracket component is engineered to withstand substantial wind loads and snow pressure, adhering to international structural safety standards for solar panel mounting hardware.

The design incorporates a mechanical clamping mechanism that distributes pressure evenly across the tile rib, preventing localized deformation. By eliminating the need for drilling, the standing seam roof clamp mitigates the risk of water leakage, a critical factor in long-term facility maintenance for industrial solar installations.

10-15 microns anodic oxidation layer

25 years service life design

60 m/s wind load resistance

Technical Specifications

Product Category

Aluminum Photovoltaic Bracket

AL 6005-T5

Surface Finish

Clear or Black Anodized

ISO 9227 (Salt Spray Test)

Fastener Hardware

Stainless Steel SUS304

A2-70 Grade

Application Profile

Color Steel Tile / Angled Rib

Non-penetrative Clamping

Wind Load Capacity

Up to 60 m/s

Structural Grade

Service Life

25 Years

Design Standard

Key Application Advantages

Non-Invasive Installation

The angle fixture design allows for secure attachment without piercing the metal sheets, preserving the manufacturer's roof warranty and preventing moisture ingress.

Enhanced Compatibility

Suitable for a wide range of trapezoidal and standing seam roof profiles, providing versatility for EPC contractors managing diverse commercial PV projects.

Structural Durability

The use of corrosion-resistant aluminum alloy ensures the system maintains its tensile strength throughout the operational lifespan of the solar array.

Efficiency in Deployment

Pre-assembled components reduce on-site labor requirements and decrease the overall solar racking installation time.

Frequently Asked Questions

How does this aluminum clamp ensure the waterproofing of the roof structure during solar installation?

The fixture utilizes a compression-based attachment method tailored for color steel tile angle mounting. Because it grips the existing ribs of the metal roof rather than requiring fasteners to penetrate the substrate, the original waterproofing layer remains undisturbed. This approach is a standard requirement for large-scale construction companies serviced by Jiangsu Aozheng Metal Products Co., Ltd. Our facility utilizes advanced automated cutting and stamping processes to ensure every clamp meets precise tolerances, preventing movement that could lead to mechanical wear on the roofing material. As an industry and trade integrated enterprise, we supply over 2,000 tons of such architectural hardware annually to high-end markets in Germany, the United States, and Australia.

What standards govern the material selection for these photovoltaic brackets in coastal or high-corrosion environments?

For installations in regions with high salinity or humidity, we utilize anodized aluminum alloy and SUS304 stainless steel fasteners. These materials are selected to prevent galvanic corrosion and maintain structural load-bearing capacity over a 25-year period. Jiangsu Aozheng Metal Products Co., Ltd. operates a professional production base where raw material molding and machining are integrated. Our expertise in stainless steel and aluminum alloy fabrication allows us to meet the rigorous demands of international construction teams. By maintaining a diversified production scale, we ensure that our components, exported to the Middle East, Canada, and South Korea, comply with global building codes for photovoltaic mounting systems.

Can these fixtures be customized for specific metal roof rib dimensions?

Yes, the internal geometry of the aluminum alloy clamp can be adjusted to match specific profile drawings provided by the client. Jiangsu Aozheng Metal Products Co., Ltd. leverages sophisticated welding and machining processes to produce customized building materials for specialized architectural requirements. We currently serve as a primary Chinese supplier for global construction firms, providing technical solutions for angled rib roof fixtures. Whether the project involves standard trapezoidal sheets or unique standing seam designs, our engineering team can facilitate the necessary modifications to ensure a secure, calibrated fit.
